Overview X-Ray Systems

Overview X-Ray Systems

<

>

X-Ray Drilling of Reference Holes

Typically the reference holes are used to inset pins, which will be used to clamp the panel with the accurate alignment to the X, Y axes of the drilling machine. To this aim, the reference holes must be executed with best optimization respect to the inner lay-up of the multi-layer panel.

Read More

X-Ray – Antares 700X

NO

1

<

>

PCB X-Ray Inspection

X-CHECK 310 MF is an X-Ray inspection desk for Multi-Layer panels, before and after the drilling process. The inspection of overlapped targets before drilling is to avoid to drill panels with high misalignment between the internal layers. After drilling, the use of X-Check 310 MF allows to evaluate the centering errors between holes and the relative pad. X-CHECK 310 MF is an evolution of previous model 300.

Read More

X-Check 310 MF

NO

2

<

>
