Via Hole Filling Technology

mass logo



Vacuum Via Hole Filling Systems

vac overview picWith a wide range of Vacuum Hole Filling systems in our portfolio, we are capable to fullfil all needs and requirements for the manufacturing of all types of Printed Circuit Boards. From our partner Mass GmbH we offer a mix of single sided, double sided, horizontal, horizontal selective and vertical via hole filling systems. Mass has developed a unique design of the Filling Head technology in which the distribution of the resists (inks) is spread in the most controlled and even manner. Due to the full vacuum of the chamber, the vertical filling system enables double sided filling of micro-, and blind via technology in a simple one step process. The horizontal systems are designed especially on request of the telecom industry. With the horizontal systems Mass offers the possibility for vacuum filling screen printing as well as selective filling capabilities.
>> learn more



 Through Hole Filling Systems

vhf 20 200For small quantities of Through Hole Filling requirements we offer two systems with the VHF-20 & VHF-200. The VHF-20 is a purely manual operated system and the VHF-200 is semi-automatic in its X,Y movement. The VHF-200 also enables working with a stencil for selective or "partial" filling of through holes. Both systems are capable of applying conductive or non-conductive resins.
>> learn more





Grinding/Planarizing

grinding allPCB manufacturers need to carefully consider these variations when chosing the type of Planarization system. It occurs regularly that PCB manufacturers use a combination of different systems for different variaties of filled via's. ADEON Technologies BV offers a range a Planarization systems in partnership with both Mass GmbH and Pola & Massa srl. We offer a solution for each type of Planarizing needs whether through technology-, production requirements or a combination of both.
>> learn more




Options

Options allA variety of options are available to suit the needs of each technology requirement. We are offering a Large Container System for automatic refilling of the Cartridge when processing higher volume, a System Cleaning Station for cleaning of the Filling Heads and a Paste recovery system unique to the VCP-5000.
>> learn more







All information subject to change without notice!

Information request

Please type your full name.
Invalid email address.
Please send us your message.
Invalid Input

About Adeon

At Adeon we believe that it is the quality of our work that placed us in our current position, and quality is what we try to improve with everything we do. European PCB manufacturers are often challenged to produce many different designs and technology levels every day. This makes it challenging to select and provide equipment that is capable of doing that. Our goal is to offer the best service and support against affordable rates to the highest standards to help our customers to stay at the forefront of technological developments.
