Drillroom Equipment

Overview Drillroom Equipment

<

>

Drillstack Preparation

Pinning & Taping machine for stack preparation before the PCB drilling process. Executes simultaneously the pinning and taping operation on the shortest edges (pin edges) and with a second cycle only the taping on the longest edges.

Read More

Combi 22

NO

1

<

>

One Head De-Pinning machine

The stack with the pins is placed on the working table with the pins turned down and pushed against a sensor that activate automatically the expulsion cycle. Neither footswitch nor button is used. After the first pin expulsion the operator turns at 180° the stack for second pin expulsion.

Read More

Depinning Single

NO

2

<

>

Depinning Twin

The stack with the pins is placed on the working table with the pins turned down and inserted in the slot. Pushing longitudinally the stack the pins are automatically intercepted and ejected one after the other in two steps.

Read More

Depinning Twin

NO

3

<

>

Stack preparation before drilling process

Executes automatically and at the same time the pinning, taping and unloading (stacking) operations on the PCB panels ready to be drilled.

Read More

Octopus

NO

4

<

>

Semi automatic & manual...

...single head MLB Pinning machine. The ML boards are positioned on the working table and coinciding the holes on the centring pins. A footswitch activate the down stroke of the pinning head, the pin insertion and the return of the centering pin under the working table. When the pinned stack is unloaded the centring pin return up ready for the next cycle.

Read More

Pinning Single

NO

5

<

>

Working Process

The Multi Layer boards are positioned on the working table and coinciding the holes on the centring pins. The pinning heads down stroke, the pins insertion are activated from two buttons which must be pushed simultaneously. After the return of the centring pin under the working table is possible unload the pinned stack and the machine will be ready for the next cycle.

Read More

Pinning Twin

NO

6

<

>

Pinning machine...

...for stack preparation prior to drilling process. The boards are positioned on the working table against the position stops on the backside. The stack during the drilling process is held in position by two pressure feet. Two synchronized drilling heads positioned under the table coming up making the holes from the bottom.

Read More

Spinamatic

NO

7

<

>

Working Cycle

The stack is placed on the plastic guides and pushed against the sensors that activate the cycle. A carriage equipped with the taping device comes forward and terminate the operation.

Read More

Taping Single

NO

8

<

>

Working Cycle

The stack is placed on the plastic guides and pushed against the sensors that activate the cycle. A carriage equipped with two taping devices comes forward and terminate the operation putting two tapes each time.om.

Read More

Taping Twin

NO

9

<

>
